Tsugami's line of Opposed Gang Tool lathes offer the widest selection of machining capacities and configurations. From basic Swiss turn lathes to advanced turning centers, the Opposed Gang Tool line is capable of milling, drilling, tapping, and threading. Minimize secondary setup times while achieving superior precision.
You are here
B075-III
Opposed Gang Tool
B075-III
Travels
Max Headstock Stroke
|
45/170 mm (1.8/6.7 in)
|
Number of Axes
|
5
|
Capacity
Max Bar Diameter
|
Ø7 mm (0.3 in)
|
Sliding Headstock/Guide Bushing
|
Yes
|
Convertible: Run w/o Guide Bushing
|
Yes
|
Spindle
Speed (Main)
|
200-15000 rpm
|
Speed (Sub)
|
200-12000 rpm
|
Power
|
2.2 kW (1.5 Hp)
|
Tooling
Tool Capacity
|
29/42
|
Machine Size
Length
|
1585 mm (40.7 in)
|
Height
|
1700 mm (66.9 in)
|
Width
|
1035 mm (64.5 in)
|
