PUMA 800L

PUMA Series

The PUMA Series is Doosan’s high performance lathe series. Designed for heavy and intermittent cutting, accurate production, and premium surface finishes, this series has a wide variety of models with chuck sizes ranging from 8”-21”, turning lengths up to 120", and options for sub-spindles, y-axis, and milling capabilities. This Series has a box guideway structure which prevents vibration and gives it secure dynamic rigidity. It has the highest spindle speed in its class and also delivers powerful cutting capabilities.

PUMA 800L

Travels
Travel Distance X-axis
470 mm (18.5 in)
Travel Distance Z-axis
3235 mm (127.4 in)
Rapid Traverse X-axis
12 m/min (472 in/min)
Rapid Traverse Z-axis
10 m/min (394 in/min)
Capacity
Max Turning Diameter
⌀900 mm (35.4 in)
Max Turning Length
3,200 mm (126 in)
Through Hole Diameter
⌀318 mm (12.6 in)
Spindle
Chuck Size
32 in
Speed
750 rpm
Power
45 kW (60 Hp)
Torque
6605 Nm (4873 ft-lbs)
Tooling
Shank
BMT-KEY
Turret Stations
12
Boring Bar Diameter
⌀80 mm (3 in)
Machine Size & Weight
Length
7,360 mm (290 in.)
Height
2,590 mm (102 in.)
Width
2,766 mm (109 in.)
Weight
21,800 kg (48,060 lbs.)
