CP 6000 / CT 6000

C Series

The C Series machining center takes out all the stops to minimize your set-up time by combining 5-axis, horizontal, and vertical milling, with tilted and vertical turning capabilities. One machining center for all machining tasks, the C Series offers options for a singular direct load or palleted tables.

CP 6000 / CT 6000

Travels
Travel Distance X-axis
1,000 mm (39.4 in.)
Travel Distance Y-axis
1,000 mm (39.4 in.)
Travel Distance Z-axis
1,300 mm (51.2 in.)
Travel Distance A-axis (Tilting Head)
+30°/-120°
Travel Distance C-axis (Swivel Head)
+15°/-190°
Travel Distance B-axis
360°
Rapid Traverse X-axis
65 m/min. (2,559.1 in/min.)
Rapid Traverse Y-axis
65 m/min. (2,559.1 in/min.)
Rapid Traverse Z-axis
65 m/min. (2,559.1 in/min.)
Rotary Table
Speed
700 rpm
Pallet Size (CP)
630 x 630 mm (24.8 x 24.8 in.)
Max Part Size (CP)
⌀1,000/1,000 x 1,580 mm (⌀39.4/39.4 x 63.2 in.)
Table Size (CT)
⌀1,000 mm (⌀39.4 in.)
Max Part Size (CT)
⌀1,580 mm (⌀63.2 in.)
Max Part Height
1,200 mm (47.2 in.)
Max Load
1,400 kg (3,086 lbs.)
Spindle
Speed
6,000/8,000/12,500 rpm
Power
43/60/80 kW (57.7/80.5/107.3 Hp)
Torque
146/350/822 Nm (107.7/258.1/606.3 ft-lbs.)
Tooling
Shank
HSK-T 100
Changer Capacity
50/100/150/265/425
Max Diameter
⌀280 mm (11 in.)
Max Length
600/800 mm (23.6/31.5 in.)
Machine Size
Length
7,700/7,950 mm (303.1/313 in.)
Height
4,400 mm (173.2 in.)
Width
5,450/6,400 mm (214.6/252 in.)
