The PUMA GT/DNT series is DN Solutions (formerly Doosan Machine Tools) Global Turning family of horizontal turning centers. These heavy-duty, box guideway machines have an 8” or 10″ chuck and a powerful 15.5 – 18.5kW/4500 rpm or 26kW/3500 rpm spindle depending on the model type. Designed to meet global standards, the GT Series will keep you competitive and productive.
You are here
PUMA GT3100LM
PUMA GT/DNT Series
PUMA GT3100LM
Travels
Travel Distance X-axis
|
260 mm (10.2 in)
|
Travel Distance Z-axis
|
1350 mm (53.1 in)
|
Rapid Traverse X-axis
|
24 m/min (945 in/min)
|
Rapid Traverse Z-axis
|
30 m/min (1181 in/min)
|
Capacity
Max Turning Diameter
|
⌀376 mm (14.8 in)
|
Max Turning Length
|
1245 mm (49 in)
|
Through Hole Diameter
|
⌀103 mm (4.1 in)
|
Spindle
Chuck Size
|
12 in
|
Speed
|
2800 rpm
|
Power
|
22 kW (30 Hp)
|
Torque
|
1124 Nm (828 ft-lbs)
|
Tooling
Shank
|
BMT-65
|
Turret Stations
|
12 Slot
|
Boring Bar Diameter
|
⌀50 mm (2 in)
|
Tooling (Milling)
Rotary Tool Speed
|
5000 rpm
|
Rotary Tool Power
|
7.5 kW (10 Hp)
|
Rotary Tool Torque
|
95.5 Nm (70 ft-lbs)
|
Machine Size & Weight
Length
|
4,465 mm (175.8 in.)
|
Height
|
2,110 mm (83.1 in.)
|
Width
|
2,325 mm (91.5 in.)
|
Weight
|
7,050 kg (15,545 lbs.)
|
