Got heavy-duty applications? Then the Mynx Series is a perfect match. This series was designed specifically for heavy-duty cutting, flawless surface finishes, and unbeatable accuracy. With box type guideways, two-step gearbox, a wide selection of spindles and other productive options, you can build the perfect heavy-duty machine for your needs.
You are here
Mynx 9500/50
Mynx Series
Mynx 9500/50
Travels
Travel Distance X-axis
|
2500 mm (98.4 in)
|
Travel Distance Y-axis
|
950 mm (37.4 in)
|
Travel Distance Z-axis
|
850 mm (33.5 in)
|
Rapid Traverse X-axis
|
16 m/min (630 in/min)
|
Rapid Traverse Y-axis
|
16 m/min (630 in/min)
|
Rapid Traverse Z-axis
|
16 m/min (630 in/min)
|
Table
Table Size
|
2500 x 950 mm (98.4 x 37.4 in)
|
Max Load
|
3500 kg (7716 lbs)
|
Spindle to Table Distance
|
200 - 1050 mm (7.9 - 41.3 in)
|
Spindle
Speed
|
6000 rpm
|
Power
|
22 kW (30 Hp)
|
Torque
|
452.5 Nm (334 ft-lbs)
|
Tooling
Shank
|
BIG PLUS CAT 50
|
Changer Capacity
|
40
|
Max Diameter
|
125/230 mm (4.9/9 in)
|
Max Length
|
350 mm (13.8 in)
|
Machine Size & Weight
Length
|
6,480 mm (255.1 in.)
|
Height
|
3,598 mm (141.7 in.)
|
Width
|
4,315 mm (169.9 in.) + 1,035 mm (40.7 in.)
|
Weight
|
23,000 kg (51,000 lbs.)
|
