TRUMPF’s one-box laser offers a comprehensive all-in-one package that easily integrates laser marking into your production line or machine. The one box laser uses minimal space without requiring a separate supply unit and features a comprehensive interface for easy installation. The one box laser is designed for low-maintenance and offers an excellent price-performance ratio.
You are here
TruMark 5010
One-Box Laser
TruMark 5010
Laser
Beam Quality
|
<1.6 M²
|
Wavelength
|
1,062±3 nm
|
Pulse Repetition Frequency
|
1-200 kHz
|
Min. Focal Diameter
|
45 µm (1,771.6 μin.)
|
Max Internal Focal Position Control
|
±24 mm (0.9 in.)
|
Max Marking Field Zone
|
170 x 170 mm (6.7 x 6.7 in.)
|
Structure
Width
|
250 mm (9.8 in.)
|
Height
|
175 mm (6.9 in.)
|
Depth
|
430 mm (16.9 in.)
|
Installation
Protection Type
|
IP54
|
Ambient Temperature
|
15-40°C (59-104°F)
|
