B0123-II

Opposed Gang Tool

Tsugami's line of Opposed Gang Tool lathes offer the widest selection of machining capacities and configurations. From basic Swiss turn lathes to advanced turning centers, the Opposed Gang Tool line is capable of milling, drilling, tapping, and threading. Minimize secondary setup times while achieving superior precision.

B0123-II

Travels
Max Headstock Stroke
45/210 mm (1.8/8.3 in)
Number of Axes
3
Capacity
Max Bar Diameter
Ø12 mm (0.5 in)
Sliding Headstock/Guide Bushing
Yes
Convertible: Run w/o Guide Bushing
Yes
Spindle
Speed
200-12000 rpm
Power
1.5/2.2 kW (2/2.9 Hp)
Tooling
Tool Capacity
13
Live Tool Capacity
4
Live Tool Speed
8000 rpm
Machine Size
Length
1035 mm (40.7 in)
Height
1700 mm (66.9 in)
Width
1640 mm (64.5 in)
