Mikron MILL X 400 U

Ultra-High Speed Machine: Mikron MILL X Series

The Mikron MILL X Series takes the features of the MILL S Series and takes it to the next level with enhanced spindle speeds of up to 42,000 rpms and travel rates of up to 100 m/min. Take the MILL X Series rapid performance even further with options for varying pallet sizes and pallet pool system for more productivity.

Mikron MILL X 400 U

Travels
Travel Distance X-axis
500 mm (19.7 in)
Travel Distance Y-axis
240 mm (9.4 in)
Travel Distance Z-axis
360 mm (14.2 in)
Travel Distance B-axis
±110°
Travel Distance C-axis
n x 360°
Rapid Traverse X-axis
100 m/min (3937 in/min)
Rapid Traverse Y-axis
100 m/min (3937 in/min)
Rapid Traverse Z-axis
100 m/min (3937 in/min)
Rapid Traverse B-axis
165 rpm
Rapid Traverse C-axis
250 rpm
Table
Table Size
Varies by Pallet
Max Load
25 kg (55.1 lbs)
Number of Pallets (Option)
18/20
Spindle
Speed
30000/42000/62000 rpm
Power
8.5/13.5 kW (11.4/18.1 Hp)
Torque
3.5/8.8 Nm (2.6/6.5 ft-lbs)
Tooling
Shank
HSK-E32/HSK-E40
Changer Capacity
18/36/68/168/308
Machine Size
Length
1811 mm (71.3 in)
Height
2850 mm (112.2 in)
Width
2373 mm (93.4 in)
