Mikron MILL X 400

Ultra-High Speed Machine: Mikron MILL X Series

The MILL X Series is GF Machining Solutions fastest line of machining centers featuring 3-axis capabilities with up to 42,000 rpm spindle speeds, 100 m/min traverse speed, and is designed to handle repeated mass production. The MILL X also has options for automated pallet pools, massive tool changer capacities, and several options for different pallet sizes.

Mikron MILL X 400

Travels
Travel Distance X-axis
500 mm (19.7 in.)
Travel Distance Y-axis
450 mm (17.7 in.)
Travel Distance Z-axis
360 mm (14.2 in.)
Rapid Traverse X-axis
100 m/min. (3,937 in./min.)
Rapid Traverse Y-axis
100 m/min. (3,937 in./min.)
Rapid Traverse Z-axis
100 m/min. (3,937 in./min.)
Table
Pallet Size
Varies by Pallet
Max Load
120 kg (264.6 lbs.)
Number of Pallets (Option)
7/10
Spindle
Speed
30,000/42,000/60,000 rpm
Power
8.5/13.5 kW (11.4/18.1 Hp)
Torque
3.5/8.8 Nm (2.6/6.5 ft-lbs.)
Tooling
Shank
HSK-E32/HSK-E40
Changer Capacity
18/20/36/40/68/168/308
Machine Size
Length
1,811 mm (71.3 in.)
Height
2,850 mm (112.2 in.)
Width
2,373 mm (93.4 in.)
