Mikron MILL S 400 U

High Speed Machine: Mikron HSM/MILL S Series

The Mikron HSM/MILL S Series machines are built with high-speed spindles, high feed rates, rapid acceleration, and 5-axis machining capabilities designed for manufacturing a wide range of complex die and mold parts. The HSM/MILL S Series is capable of reaching speeds 10 times faster than conventional milling machines and features model options specifically designed for Graphite and Precision machining.

Mikron MILL S 400 U

Travels
Travel Distance X-axis
500 mm (19.7 in)
Travel Distance Y-axis
240 mm (9.4 in)
Travel Distance Z-axis
360 mm (14.2 in)
Travel Distance B-axis
±110°
Travel Distance C-axis
n x 360°
Rapid Traverse X-axis
61 m/min (2401.6 in/min)
Rapid Traverse Y-axis
61 m/min (2401.6 in/min)
Rapid Traverse Z-axis
61 m/min (2401.6 in/min)
Rapid Traverse B-axis
165 rpm
Rapid Traverse C-axis
250 rpm
Table
Table Size
Varies by Pallet
Max Load
25 kg (55.1 lbs)
Number of Pallets (Option)
18/20
Spindle
Speed
30000/42000/62000 rpm
Power
8.5/13.5 kW (11.4/18.1 Hp)
Torque
3.5/8.8 Nm (2.6/6.5 ft-lbs)
Tooling
Shank
HSK-E32/HSK-E40
Changer Capacity
18/36/68/168/308
Machine Size
Length
1811 mm (71.3 in)
Height
2850 mm (112.2 in)
Width
2373 mm (93.4 in)
